Consequently, the above mentioned question

should be answered negative. The native knee

has a typical passive kinematic pattern, as des-

cribed in several papers using different metho-

dology [4, 6, 7, 11, 17, 19, 20], however, the

largest joint in the human body is capable of

adapting to many different kinematic patterns,

depending on extrinsic conditions [18-20].

HOW DO NATIVE KNEE

KINEMATICS RELATE TO

TKA KINEMATICS?

As the native knee is moving as guided by its

articular geometries, gravitational and muscle

loads, within the limits of its ligaments, the

arthroplasty joint should function within this

so-called ‘envelope of function’. The implant

bearing surfaces and intrinsic constraints

should ideally compensate for the functions of

passive structures that are missing due to disea-

se or eliminated/modified by joint replacement.

This is a delicate exercise as insufficient ‘com-

pensation’ will lead to subtle instability. Many

papers have referred to the so-called ‘para-

doxical motion’, indicating an abnormal for-

ward motion of the femoral condyles during

flexion [21-23]. The clinical consequence of

this abnormal motion is unclear. The surroun-

ding tissues are certainly capable of coping

with this motion pattern but it leads to a less

favorable moment arm for the quadriceps sys-

tem, inducing relative weakness of knee exten-

sion. If the forward translation of the femur

occurs in deeper flexion, posterior tibiofemo-

ral impingement leading to decreased flexion

can result. This is probably the explanation for

the observed lesser flexion of cruciate retai-

ning knees as compared to posterior stabilised

devices [23, 25].

On the contrary, overzealous ‘compensation’ in

an attempt to reproduce the passive kinematic

pattern of the native knee also carries risks. We

helped design a knee arthroplasty mimicking

normal passive knee kinematics through gui-

ded motion. [26] Using the experimental kine-

matic model, the kinematics of the device were

validated in the passive setting, but as the knee

was loaded, the prosthesis did not adapt to the

typical changes induced by muscle loading [19,

24]. The increased posterior translation in the

lateral compartment of the prosthetic knee as

compared to the loaded native knee was belie-

ved to explain the iliotibial traction syndrome

we noticed in 7% of the patients treated with

this motion guided knee design [27].

It is clear that knee kinematics will not only

depend upon the implant design. Geometric ali-

gnment will largely affect post-operative knee

kinematics. Alignment mistakes can be gross

and lead to frank stiffness and largely unsatis-

factory results or subtle, leading to suboptimal

clinical results. An example is shown in

figure 5. The concept of a single radius design

is widespread, and promoted by virtue of its

more natural kinematics. One cannot consider

this geometric feature of the prosthesis having

a single radius, without taking the soft tissues

into account. In the example shown, the femo-

ral component is undersized and the joint line

raised as compared to the native knee (e.g. a

femoral component size 5 in stead of 6). The

surgeon compensates with a thicker polyethy-

lene insert (e.g. 14 mm in stead of 10 mm). In

the normal knee, the MCL is isometric and

inserts close to the centre of rotation of the

medial condyle on a 2D model [28]. The centre

of rotation of the knee is represented by the red

dot. In the prosthetic setting with the smaller

femoral component and the raised joint line, a

new centre of rotation will be created, repre-

sented by the blue dot. The MCL, represented

in clear blue, is nicely tensioned in full exten-

sion. As the knee goes to mid flexion, slacke-

ning of the MCL occurs as the insertion of the

MCL does not coincide anymore with the new

centre of rotation of the medial condyle, repre-

sented by the blue dot. In 90° of flexion, ten-

sion is normal again but in deeper flexion the

MCL is pulled tighter by the anisometric new

centre of rotation.

This example clearly illustrates how a ‘kine-

matic feature’ of a prosthesic design is influen-

ced by subtle surgical variability

COMPARATIVE KINEMATICS BETWEEN THE NATIVE KNEE AND TOTAL KNEE ARTHROPLASTY
