KNEE KINEMATICS

The description of the relative motion between

rigid bodies is called kinematics. As the knee

joint is the largest joint of the human body

with an intricate anatomy, its kinematics have

intrigued researchers since a long time [1].

Apart from direct visual observation, the most

popular tool for studying the joint was radio-

graphy. The knee was treated as if it were a

‘planar mechanism’ [2]. In other words, the

movement of the knee was reduced to a two-

dimensional projection of a three-dimensional

reality. In the years following, the limitations

of this methodology became clear, with the

major flaw being the inability to ascertain the

location of the axes of rotation before perfor-

ming kinematic analyses [3]. In 1983, Grood

and Suntay presented a joint coordinate system

providing a geometric description of the three-

dimensional rotational and translational

motion between two rigid bodies, applied to

the knee joint. With this model, the described

joint displacements became independent of the

order in which the component rotations and

translations occur [4]. The new mathematical

insights led to the concept of the helical axis

and opened the door for a correct scientific

description of the kinematics of the knee, allo-

wing six degrees of freedom [5]. However, as

the mathematical accuracy improved, the com-

plexity increased and the model appeared to be

impractical and difficult to apply to the clinical

setting: the clinicians failed to understand the

engineers.

Hollister, and later Churchill, tried to bridge the

gap, reducing the descriptive model to essen-

tially two degrees of freedom [6, 7]. Hollister’s

model described knee motion as pure rotations

occurring around two axes: the so called

‘flexion-extension axis’ and the so called ‘lon-

gitudinal rotation axis’, with the understanding

of the flexion-extension axis not being exactly

located in the coronal plane and the longitudi-

nal axis not being exactly located in the sagittal

plane [6]. As a consequence, these mathemati-

cal ‘simple rotations’ meant in reality flexion-

extension, varus-valgus and internal-external

rotation of the knee joint, confusing the clini-

cian trying to apply this knowledge to the prac-

tical setting. Churchill addressed this problem

by allowing a mathematical error in the kine-

matic description, based on a loaded rig expe-

riment with an ankle load of 100 N and a com-

bined hamstrings load of 30N [7]. The advan-

tage of this approach was the link between the

kinematic description and certain anatomic

landmarks, allowing clinicians to apply this

knowledge in practice.

165

COMPARATIVE KINEMATICS BETWEEN

THE NATIVE KNEE AND TOTAL KNEE

ARTHROPLASTY

J. VICTOR
