MATERIALAND

METHODS

We choosed patients with varus or valgus

malalignment greater than 10° and patients

with normal alignment that underwent TKA.

The patients were randomly chosen out of a

pool of over 2,400 operated patients.

Exclusion criteria

Patients with an extension deficiency greater

than 5° to avoid false results in leg length mea-

surements in the AP-view were excluded [1].

Preoperative assessment and planing

As this study is a retrospective analysis all the

patients included were preoperatively exami-

ned as usual in our clinic. The radiological

documentation included standard knee radio-

graphs, a standing AP view, a lateral view,

stress XRays, a patella view in 45° flexion and

an AP long-leg weight-bearing view. The range

of passive motion was measured with a gonio-

meter and the IKS knee score was calculated.

Postoperative follow-up

The usual postoperative follow-up was classi-

cal with physiotherapy and full weight bea-

ring. Radiographic follow up was performed at

6 Weeks and one year. The radiological docu-

mentation included standard knee radiographs,

a standing AP view, a lateral view, a patella

view in 45° flexion and an AP long-leg weight-

bearing view. The range of passive motion was

again measured with a goniometer and the IKS

knee score was calculated.

Material

We decided to study the change in leg length

in three groups. The groups were formed as

follows.

• Group 1

(n1=10) varus malalignment >10°

(AFTm >170°)

• Group 2

(n2=10) valgus malalignment >10°

(AFTm >190°)

• Group 3

(n3=10) normal aligned (AFTm ±2°)

Measurements

Measurements were accomplished as following

(fig. 1). Our first method was to measure leg

length on preoperative AP long-leg weight-

bearing radiographs. We defined the leg length

(c) as the distance between the centre of the

femoral head (CFH) and the centre of the

ankle (B), this line is equal to the mechanical

axis and also known as the Mikulic line. We

then measured the distance (b) between the

centre of the femoral head and a tangent to the

femoral condyles (TC) on a line going

through the CFH and the interconylar point.

The crossing point of (b) with TC was marked

C. Then we measured the distance (a) between

the centre of the ankle (B) and point C. It sho-

wed that in our groups a was identical with to

the mechanical tibial axis. In this way we

created a triangle with the angle gamma on

the medial side of the knee in the corner/point

of C which we compared with the same tri-

angle drawn on the postoperative radiograph.

In this way we had a direct comparison of all

three sides of this triangle and the angle

gamma. Then we compared the measured leg

length (c) postoperative with the predicted leg

length calculated out of

γ

gamma postoperati-

vely and a and b preoperatively.

We also measured the length of centre ankle (B)

to joint line (JL), femoral length (LF) on the ana-

tomical axis by measuring the distance between

the crossing point of the femoral anatomical axis

(FAA) with the tangent to the femoral condyles

and a point D on the femoral axis which is the

crossing point of a perpendicular line to the ana-

tomical axis going through the CFH.

We then developed a second way to measure a

possible lengthening in the knee joint by crea-

ting a fix-point on tibia (T) and femur (F) as
